Reverse Video Interface Nissan Interstar OpenR Link 10

Video inserter for rear-view-camera, front camera with auto switching and 2 further video-inputs. CVBS and AHD compatible

REQUIRES DISASSEMBLY OF THE RADIO
Opening the radio to install this kit will void that radio's warranty.
The internal components of this radio are extremely delicate, and the installation of this kit may damage the radio.  By purchasing this kit, the customer agrees to take all responsibility for any damage caused to the radio due to removal, disassembly or installation.
Incarsolution strongly recommends the installation of this interface by our partners.

PRODUCT FEATURES
1 CVBS/AHD-input for rear-view camera
1 CVBS/AHD-input for front camera
2 CVBS/AHD-input for side-cameras or additional after-market video-sources (e.g., USB-device, DVB-T2 Tuner, etc.)
All inputs NTSC and PAL compatible
Supported AHD resolutions 720p NTSC (30Hz), 720p PAL (25Hz), 960p NTSC (30Hz), 960p PAL (25Hz), 1080p NTSC (30Hz), 1080p PAL (25Hz)
1 HDMI-input for HD rear-view camera or additional HDMI-sources (e.g., IOS/Android, laptop, streaming stick, DVD-Player, DVB-T2 Tuner, etc.)
Automatic switching to rear-view camera input while reverse gear is engaged
Automatic front camera switching after reverse gear for 5, 10, 15 or 20 seconds
Activatable driving-path lines for rear-view camera (not available for all vehicles)
Picture free during the car ride (only for inserted video-sources)

NAVIGATION SYSTEM
OpenR-Link Radio/Nav with 10inch monitor

HOW TO IDENTIFY THE NAVIGATION SYSTEM


VEHICLE COMPATIBILITY
Nissan Interstar 11/2024 →

To ensure compatibility, we recommend that the parts pictured in our listing are compared to the actual parts in your vehicle before you make your purchase. If still unsure please contact us via email system so we can advise before you make your purchase.
